Metal Warehouse Building Technical Parameters
Low Cost Prefab Small Steel Warehouse / Metal Shed Kit
Application Storage, Workshop, Garage, Farm Shed, Logistics Station, Construction Site Office
Structure Type Portal Frame / Multi-story / Truss Structure
Design Standard GB (China), AISC (USA), Eurocode (EU), AS/NZS (Australia) - Customizable
Steel Material Q235B, Q355B, Q345,ASTM A36, ASTM A572 Gr.50
Span (Width) 5m - 80m (Customized)
Length Unlimited (Based on site)
Eave Height 4m - 20m (Customized)
Crane Support None, 5T, 10T, 20T, 50T+
Wind Resistance Up to 140 km/h (Customized per location)
Snow Load Up to 1.5 kn/m² (Customized)
Surface Treatment Sandblasting Sa2.5 + Epoxy Paint / Hot-dip Galvanized
Roof Slope 5%, 10%, 15% (Recommended 10% for drainage)
Roof & Wall Sheets
Option A: Corrugated Steel Sheet (0.4mm - 0.6mm thickness)
Option B: Sandwich Panel (EPS, Rock Wool, PU, Glass Wool)
Color Options RAL Color Chart (Popular: White, Blue, Red, Grey, Green)
Panel Thickness 50mm, 75mm, 100mm (For insulated options)
Main Door Rolling Shutter Door (Electric/Manual), Sliding Door, Swing Door
Side/Personnel Door Steel Security Door, Aluminum Alloy Door
Windows PVC/Aluminum Sliding Windows, Louver Windows (for ventilation)
Certificate ISO9001, CE, SGS Test Reports Available,C/O.
Supply Ability 10000 Tons per Month
Delivery Time 10-30 Days after drawing confirmation
Service Life 50 years

Packaging & Delivery
Packing Method Nude Packing for steel frames (bundled with steel strips) Stacked Packing for sheets/panels (protected by foam & cardboard)
Container Loading Optimized loading plan to maximize space (e.g., 200-300 sqm fits in 1x40HQ)
Delivery Time 15-25 Days after deposit and drawing confirmation
Installation Guide Detailed PDF Drawings + Step-by-Step Video Tutorial Provided
On-site Support Engineers available for overseas guidance (Extra cost)

Cost Effective Construction

Metal warehouse buildings are designed to optimise material usage, reducing waste and overall costs. Factory production lowers labour requirements and shortens project timelines, making it a highly economical choice.

Fast Installation

All structural components are pre-engineered, pre-cut and pre-drilled before delivery. This allows for quick and efficient assembly on-site, significantly reducing construction time compared to traditional methods.

High Strength And Durability

Constructed from high-quality steel, metal warehouse buildings provide excellent resistance to harsh weather conditions such as heavy rain, strong winds and seismic activity. Protective coatings like galvanisation improve corrosion resistance and extend service life.

Flexible And Customisable Design

These buildings can be tailored to meet various requirements, including size, layout and function. Whether for small storage units or large-scale logistics centres, metal warehouse buildings offer flexible design options.

Environmentally Friendly

Steel is fully recyclable, making metal warehouse buildings an eco-friendly solution. Reduced construction waste and efficient use of materials help minimise environmental impact.
