Clear Light Weight Fiberglass Roof Tile Technical Parameters
Clear Light Weight Fiberglass Roof Tile,ASA synthetic resin tile, APVC anti-corrosion composite tile, PVC anti-corrosion tile, PVC sink, PVC plate, FRP transparent tile, PVC, PC transparent tile.
Item Index Item Index
Tensile Strength (MPa) 155 Barcol 52
Tensile Modulus (GPa) 7.75 Water Absorption (%) 0.126
Flexural Strength (MPa) 223 Thermal Deformation (ºC) ≥200
Flexural Modulus (GPa) 8.30 Thermal Conductivity (w/m. k) 0.158
Wet Flexural Strength (MPa) 217 Proportion (g/cm3) 1.4
Wet Flexural Modulus (GPa) 8.43 Temperature Range (ºC) -40~130
Punching Shear Strength (MPa) 125 Flash Point (ºC) 410
Punching Shear Modulus (GPa) 2.5*10-5 UV Resistant (%) 99.99

FRP Skylight Sheets is a wonder composite material consisting of Fiberglass reinforcement in a matrix of UV Stabilized unsaturated polyester sheet grade resin system forming a tough laminate in desired profile having exceptional strength to weight ratio. FRP offers almost unlimited possibilities for shape, size, profile and color and known for its high strength, durability, water/chemical proof, dimensional stability, high resistance to environmental corrosion due to extremes of temperature and weather including emission of natural and Industrial Chemical fumes. FRP Sheets are light in weight, good aesthetic appeal, easy to install and maintain.

Applications
•Industrial Building Roofing/ Cladding for Natural lights.
•Architectural Building/ Institutions/ Airport for natural lights & aesthetic look.
•Industrial Roofing/ Cladding of Chemical Plants using special surface coatings in Translucent & opaque finish.
•Cladding/ Louvers Sheets for cooling towers against harsh weathering & corrosive environment.
•Green House Roofing sheets.
•Parking areas/ Walkways/ Garages.
•Roofing/ Cladding & Buildings for coastal areas to protect against harsh corrosive environment.
UV-Protection Greenhouse Building Material Fiberglass Roof Tile
