Frame Structure: |
Project |
Specifications |
Unit |
Quantity |
|
Top Frame: |
Top Long Beam: 2.3mm Galvanized Steel, Top Frame 180mm |
Pieces |
2 |
|
Top Short Beam: 2.0mm Galvanized Steel, Top Frame 180mm |
Pieces |
2 |
|
Bottom Frame: |
Bottom Long Beam: 2.3mm Galvanized Steel, Bottom Frame 160mm |
Pieces |
2 |
|
Bottom Short Beam: 2.0mm Galvanized Steel, Bottom Frame 160mm |
Pieces |
2 |
|
Columns: |
Column: 2.3mm C-shaped Galvanized Steel, 160*160mm |
Pieces |
4 |
|
Bolts: M12*25mm High-strength Carriage Bolts |
Set |
64 |
|
Angle Heads: |
160*160mm, Wall Thickness 4.0mm |
Set |
8 |
|
Powder Coating: |
Powder Coating: |
Electrostatic spray process, does not fade for 5 years |
Suite |
1 |
|
Pressing Slot |
Top Beam Pressing Slot: Alloy Profile Thickness 1.0mm |
Pieces |
2 |
|
Top Short Beam Pressing Slot: Alloy Profile Thickness 1.0mm |
Pieces |
2 |
|
Square Tube System |
Chassis Purlin |
50mm*100mm Galvanized Square Tube, Thickness 1.2mm |
Pieces |
9 |
|
Top Plate Purlin |
50mm*50mm Galvanized Square Tube, Thickness 1.5mm |
Pieces |
2 |
|
50mm*50mm Galvanized Square Tube, Thickness 1.1mm |
Pieces |
1 |
|
40mm*60mm Galvanized Square Tube, Thickness 1.1mm |
Pieces |
6 |
|
Door Frame Column |
20mm*40mm Galvanized Square Tube, Thickness 1.1mm |
Pieces |
1 |
|
Wall |
Rock Wool Wall Panel |
Color steel composite board thickness 50 mm, color steel double-sided thickness 0.3 mm, PE film attached, white color,
double-sided ribbed; PU sandwich panel |
set |
1 |
|
Door & Window |
Steel Door |
Steel package door, size ≥ W925 mm × H2035 mm, fire door lock |
piece |
1 |
|
External Window |
PVC window with double glass, 0.93*1.2 m |
pieces |
2 |
|
Other |
Interior Floor |
Bulu Board Thickness: 1.8m |
pieces |
5 |
|
Roof Waterproof Tile |
Single-layer Color Steel Waterproof Tile with Interlocking Thickness: 0.3mm |
sheets |
6 |
|
Roof Insulation Layer |
Glass Wool Roll, Thickness: 40mm, Density: 20kg/m3, Non-combustibility Class A |
roll |
1 |
|
Interior Ceiling Tile |
0.3 mm double-layer color steel 831 type corrugated tile |
sheets |
6 |
|
Other Auxiliary Materials |
Includes all standard screws, structural adhesives, etc. |
set |
1 |
Electrical system |
Electrical Configuration |
1. Standard national standard wire; incoming wire 4, air conditioner socket 4, general socket 2.5, lighting 1.5. (Circuits can be
customized to meet certification requirements of different countries) |
Set |
1 |
|
2. Circuit breaker system; 2P63A main switch 1 |
Set |
1 |
|
3. Lighting; LED ceiling light*2. |
Set |
1 |
|
4. Five-hole socket*4; standard three-hole socket*1 (socket standard can be configured according to customer requirements) |
Set |
1 |
|
Performance Parameters |
Insulation Performance |
λ=0.048 W/m·K |
|
Sound Insulation Performance |
Sound insulation level ≥ 30 dB |
|
Waterproof Performance |
360-degree bite, free drainage, 16 mm/min precipitation without leakage |
|
Floor Live Load |
2.0 KN/㎡, 400-500 kg per square meter |
|
Wind Resistance |
0.6 KN/㎡, withstand 11-12 level wind |
|
Fire Resistance |
A grade |
|
Earthquake Resistance |
≥ 8 level |
|
Temperature Range |
-45°C to 60°C |
|
Bathroom |
Bathroom (Optional) |
Glass door for bathroom * 2 (frameless glass door optional), 1 set of toilet, 1 set of washbasin, 1 handheld shower, floor drain,
plumbing |
Set |
1 |
|
Cabinet |
Kitchen Cabinet (Optional) |
Integrated kitchen marble cabinet with sink and pipes，Size can be customized, please contact customer service. |
Set |
1 |
|
Terrace |
Terrace (Optional) |
includes wood-plastic flooring, guardrails |
Set |
1 |
|
Elevated Container Bottom |
Bottom of Box Raised |
|
Set |
1 |
|
Roof Cover |
Roof Cover (Optional) |
Sloping roof, enhances overall appearance and facilitates drainage, material options: composite panels, EPS panels, resin tiles,
including keel. |
